INTRODUCTION

Please read this instruction carefully before use to ensure a perfect experience. If there is any additional requirement about this product, please consult the local agent or contact us through our website: www.vaporesso.com

EXPLODED VIEW

PACKING LIST

1 x GTX GO 40 Battery
1 x GTX POD 22 (3.5ml/2ml TPD)
1 x GTX 0.6Ω MESH Coil

1 x Type-C USB Cable
1 × User Manual
1 × Warranty Card

USE INSTRUCTIONS

Install the POD
Connect the battery and the pod by magnetic absorption, please ensure the assembly is stable.
Replace the Coil
- Place the drip tip of the pod face down, and pull out the used coil;
- Install a new coil to the pod;
- Press the coil to align the coil base with the pod.
  * Refer to the figure 1.
- Unscrew the top cap from the pod refer to the arrow;
- Fill e-liquid through the filling slot;
- Screw the top cap to reinstall it back into place as shown;
- Please wait 5 minutes for the e-liquid to soak into the coil completely.
  * Refer to the figure 2.
Fill E-liquid
Adjust the Airflow
Please rotate the pod to match the air-inlet port with the battery to adjust the airflow volume.
System Operating
1. Power on/off: press the power button 5 times in 2s.
2. Start Vaping: press and hold the power button to start vaping. For your safety, please do not vape for more than 10 seconds at a time.
3. Battery Indicators:

LED Color	Battery Status
	High (70%-100%)
	Medium (30%-70%)
	Low (0%-30%)

PROTECTIONS

Protections	Situation	Indicator
Low Resistance Protection	The device detects an ultra-low resistance when start to vape.	x 5 Stop Output
Short-circuit Protection	The device detects a short circuit.	x 5 Stop Output
No Load Protection	The device does not detect an atomizer when start to vape.	Low Battery: x 5 Stop Output Medium Battery:x 5 Stop Output High Battery: x 5 Stop Output
High Resistance Protection	The device detects an ultra-high resistance when start to vape.	Low Battery: x 5 Stop Output Medium Battery: x 5 Stop Output High Battery: x 5 Stop Output
Low Voltage Protection	The battery voltage drops too low when start to vape.	x 3 Stop Output
Over Charge Protection	The device is fully charged.	Stop Charging
Over Discharge Protection	The battery voltage drops too low during vaping.	x 3 Stop Output
Auto-Shut off Protection	Constantly vape for 10 seconds or more.	Low Battery: x 3 Stop Output Medium Battery: x 3 Stop Output High Battery: x 3 Stop Output
Over Heat Protection	The device detects a high temperature PCBA.	x 5 Stop Output

CAUTIONS

Please turn off the device when it is not in use.
Do not leave the charging device unattended.
Do not drop, throw or abuse your device, which may cause damage.
Please use a standard USB output charger with proper charging current and voltage range.
Keep away from the water or any flammable gas, liquid.
Do not expose the device to direct sunlight, dust, moisture or mechanical shock.
Do not expose the device to extreme temperature. (Recommended temperature range: -10~60℃ /14~140℉ while using and -10~45℃ /14~113℉ while storing).
EEE Recycling: the product should not be treated as household waste, instead, it should be handed over to the applicable collection point for the recycling of electrical and electronic equipment.
Battery Recycling: the product battery should not be treated as household waste, instead, it should be handed over to the applicable used battery collection point for recycling.
Only have your device repaired by Vaporesso. Do not attempt to repair it by yourself as damage or personal injury may occur.

SPECIFICATIONS

Dimensions: Ø22 x 110.3mm
Coil: GTX 0.6Ω MESH Coil (20-30W)
Pod Capacity: 3.5ml /2ml
Output Power: 5-40W
Output Voltage: 0-4V
Resistance Range: 0.1-2Ω
Battery Capacity: Built-in 1500mAh
Charging: DC 5V/1A, Type-C
